MOTOR OS GF30 II (70T2) W/F-6040 SILENCER 3A010

Description:

There are many attractive airplanes for 4-stroke engines in the 120/150 size range on the market. The GF30II is a perfect match for aircraft in this category. The new carburetor 70T is designed for easy adjustment and stability. The IG-07 ignition features a new spark plug cap that can be easily placed on the spark plug. The spark plug cap can be freely adjusted on the spark plug, allowing you to choose the best angle depending on the layout. The F-6040 muffler dampens noise and produces the typical 4-stroke exhaust sound. The linear throttle response is suitable for both scale and aerobatic airplanes. A long-awaited radial mount will also be released as an optional part. The package includes instructions, ignition, propeller mounting materials, spark plug, and muffler.

Features:

• Fuel mixture oil/gasoline: 1:30
• Width: 80 mm
• Shaft thread: 5/16"-24 UNF-2A
• Mounting hole spacing longitudinal: 54 mm
• Carburetor: WT1024
• Total weight approx.: 980 + 140 silencer g
• Height approx.: 161 mm with spark plug
• Mounting hole diameter: 5.7 mm
• RPM range approx.: 1800-9000 RPM
• Bore: 36 mm
• Mounting hole spacing transverse: 70 mm
• Displacement: 29.94 cm³
• Power kW (HP) at: 2.0 (2.8) 9000 RPM
• Recommended propeller: 18x8-20x10"
• Length to hub: 155 mm
• Stroke: 32.4 mm OS3A010.

Specifications:

• Engine type: Internal combustion engine
• Cubic capacity: 29.94 cm3
• shaft diameters: 5.70 mm
• Max. Speed: 9000 rpm
• Item number: 13578169

Product dimensions:

• Length: 15.50 cm
• Width: 8 cm
• Height: 16.10 cm
• Weight: 1010 g
